KNEWCONCEPTSSKU: SFBB00115
KNEWCONCEPTS® Mk3 5" FRET SAW WITH LEVER TENSION AND SWIVEL BLADE CLAMPS
$179.63
/
KNEWCONCEPTS® Mk3 5" FRET SAW WITH LEVER TENSION AND SWIVEL BLADE CLAMPS
$179.63
/
KNEWCONCEPTS® Mk3 5" FRET SAW WITH LEVER TENSION AND SWIVEL BLADE CLAMPS
$179.63
/
Low Stock (10)
Payment & Security
|
Product Name
|
5" Mk.III FRET SAW WITH LEVER TENSION AND SWIVEL BLADE CLAMPS
|
|
Model No.
|
125.005CS
|
|
Description
|
Designed to swing the rear of the frame out of the way. The ability to set the frame into a "neutral corner" frees you to saw into areas that were never possible before. It swivels 45° degrees either to the Right or the Left, and has a lock at the “straight ahead” position. Truly the ultimate in saws.
|
|
Material
|
Anodized aircraft grade aluminum
|
|
Weight
|
148.3g
|
|
Blade length
|
5 inches
|
|
Place of origin
|
Made in the USA
|
5" Mk.III FRET SAW WITH LEVER TENSION AND SWIVEL BLADE CLAMPS
Features:
- Swiveling blade clamps allow blade to rotate 45° to either side to allow off axis cuts.
- Spring loaded blade clamps snap into locking positions at 45°to either side, or 0'-straight ahead.
- Cam release tension lever
- Screw for fine tension adjustments
- 5 1/8"blade ruler built into spine for checking blades
Blade Removal
- Flip the lever 180 degrees, towards the front, as shown at left.
- Loosen both of the clamp screws by turning them counter-clockwise.
- Remove saw blade
Check the Saw Blade length
Before sawing, check the length of the saw blades.
The standard length for jewelers /fret saw blades is 5 1/8".
All sizes of aluminum frame have a blade ruler built into the spine.
There are two flat spots on the walls of the windows indicated in the main photo above. They are exactly 5 1/8"apart.
There are two flat spots on the walls of the windows indicated in the main photo above. They are exactly 5 1/8"apart.
Check your blades between them. If the blades are too long, use wire cutters to shorten the blades. Blades that are shorter than standard will not work.
